Bench Support Connector

The S-SEN Metal Bench Support Connector is a precision-engineered structural component designed for modern greenhouse seedling systems. As a core element in seedbed stability, this connector secures the support frame to ensure long-term durability under heavy cultivation loads. Produced by S-SEN Metal, a leading manufacturer in China’s hardware capital, these connectors are treated with advanced anti-corrosion processes to withstand the high-humidity environments typical of professional nursery operations.

Send Inquiry

Product Description

S-SEN Metal Bench Support Connector: Technical Features

1. Structural Stability and Load Distribution

Interlocking Design: Features a precise geometric fit that prevents rod displacement or loosening over time.
Load Capacity: Engineered to support over 50kg/㎡ when integrated with reinforced mesh frames, suitable for multi-layer seedling trays.
Weld-Free Assembly: Designed with pre-positioned mounting holes for efficient on-site construction without specialized welding equipment.

2. Environmental Resistance and Material Strength

Greenhouse conditions require specific material protection. The S-SEN Metal Bench Support Connector utilizes a post-welding hot-dip galvanizing process to ensure comprehensive coverage.

Zinc Coating: 600g/㎡ thickness provides a barrier against oxygen and moisture.
Salt Spray Testing: Verified for 2,000 hours without red rust formation.
Base Material: Constructed from low-carbon steel for high toughness and impact resistance.

Product Specifications

Specification Item	Technical Data
Material	High-Quality Low-Carbon Steel
Surface Treatment	Hot-Dip Galvanized (HDG)
Compatible Grid Sizes	20mm × 100mm to 50mm × 200mm
Wire Diameter Range	2.5mm - 4.5mm
Surface Flatness Error	≤2mm/m²

Why Source from S-SEN Metal?

S-SEN Metal (Cangzhou Shengsen Hardware Products Co., Ltd.) operates from Nanpi County, the renowned "Hardware Capital of China." Our facility is ISO 9001 certified, ensuring that every Bench Support Connector leaves the factory meeting international quality management standards.

Manufacturing Capabilities

Advanced Equipment: Utilizing CNC machine tools, laser cutting, and precision stamping for high dimensional accuracy.
Customization: We adjust connector diameter and thickness based on specific greenhouse spans and crop types.
Global Reach: Our hardware solutions are widely used in North America, Australia, and Southeast Asia.

Verified Application Case

Project: Commercial Flower Nursery (Queensland, Australia)

Requirement: A support system capable of withstanding constant irrigation and high humidity.

Solution: S-SEN Metal provided custom-sized Bench Support Connectors with 600g/㎡ zinc coating.

Outcome: The system has maintained structural integrity for over 5 years with zero reported corrosion failures, significantly reducing maintenance overhead.

Frequently Asked Questions

Does the connector require specialized tools for installation?

No, the S-SEN Metal Bench Support Connector features a weld-free, bolt-together design that allows for assembly with standard hand tools, facilitating fast on-site setup.

Can these connectors be used for multi-tier seedling racks?

Yes. Due to the high load-bearing capacity and reinforced welding points, they are frequently used in vertical farming and multi-layer tray systems.

What is the lead time for customized orders?

Standard specifications are often in stock. For customized dimensions or specific hole patterns, lead times vary based on quantity, typically ranging from 15 to 30 days.
